14m Telehandler (JLG 3614RS) hire
**Minimum of a 3 day hire period on this machine**
The 14m Telehandler (JLG 3614RS); from the RS series of JLG telehandlers offering simplicity without compromise as well as added comfort, improved serviceability. Constructed with proven components, it is not only attractive but very productive and offering all the power you need. While reliability is the foundation for any equipment, the 3614RS also offers a smart, clean design, quality and dependability. The performance offers a 3600kg maximum lift capacity and a 14m (46ft) maximum lift height.
JLG 3614RS Product Features:
- A maximum lift height of 14m
- Proven power train - with integrated powershift 3-speed transmission and feature Dana axles.
- Simplified boom design so there is less service and easier access provided.
- Well spaced cabin with controls placed in front of the operator.
- Longer wheel base providing greater stability and comfort when driving and landing loads.
View the product information for the JLG 3614RS 14m Telehandler
Weekend Hire Policy:
Hire Friday after 12pm and return by Monday 10am and pay the weekend rate.
Place your hire request:
Transport Code: 6
*Exact transport costs will be calculated with depot
Large Access Transport Guideline
Up to 10 miles:
£85 Each way
11-20 miles:
£150 Each way
21-30 miles:
£170 Each way
14m Telehandler (JLG 3614RS) in action
Specifications
| Max. lift height | 14m |
|---|---|
| Drive | 4×4 |
| Max. travel speed | 25km/h (15.5mph) |
| Tires | Mitas 15.5 / 80-24ply |
| Steering | Two wheel / four wheel / crab steer with push button select facility |
| Transmission | 3 Speed forward and reverse |
| Max. torque | 420nM |
| Engine gross power | 74.4kW |
| Engine | Deutz TCD 3.6 L4 |
| Outside turning radius | 3.85m |
| Length (less forks) | 6.34m |
| Approximate operating weight | 9800kg |
| Max. forward reach | 9.23m |
| Capacity @ max. lift height | 3000kg |
| Rated capacity | 3600kg |
| Ground clearance | 414mm |
| Wheelbase | 3.15m |
| Height | 2.67m |
| Width | 2.35m |
| Fram tilt left / right | 10 degrees |
